MT40A1G4RH-083E:B IC DRAM 4GBIT PAR 1.2GHZ 78FBGA Micron Technology Inc.



DESCRIPTION

These 1500 watt transient voltage suppressors offer power-handling capabilities only found in larger packages. They are most often used for protecting against transients from inductive switching environments or induced secondary lightning effects as found in lower surge levels of IEC61000-4-5. With very fast response times, they are also effective in protection from ESD or EFT. Powermite® package features include a full metallic bottom that eliminates the possibility of solder-flux entrapment during assembly. They also provide unique locking tab acting as an integral heat sink. With its very short terminations, parasitic inductance is minimized to reduce voltage overshoots during fast-rise-time transients.





FEATURES

• Very low profile surface mount package (1.1mm)
• Integral heat sink-locking tabs
• Compatible with automatic insertion equipment
• Full metallic bottom eliminates flux entrapment
• Voltage range 5 volts to 170 volts
• Available in both unidirectional or bi-directional (C suffix for bi-directional)





MAXIMUM RATINGS

• Operating Temperature: -55°C to +150°C
• Storage Temperature: -55°C to +150°C
• 1500 Watt peak pulse power (10 / 1000 µsec.)
• Forward Surge Current: 200 Amps at 8.3 ms (excluding bidirectional)
• Repetition surge rate (duty factor): 0.01%
• Thermal resistance: 2.5°C / watt junction to tab 130°C / watt junction to ambient with recommended footprint
• Lead and mounting temperature: 260°C for 10 sec





APPLICATIONS / BENEFITS

• Secondary lightning transient protection
• Inductive switching transient protection
• Small footprint
• Very low parasitic inductance for minimal voltage overshoot
• Compliant to IEC61000-4-2 and IEC61000-4-4 for ESD and EFT protection respectively and IEC61000-4-5 for surge levels defined herein
