NJU77551F-TE1 IC OPAMP GP 1 CIRCUIT SOT23-5 Nisshinbo Micro Devices Inc.
| Brand Name | Nisshinbo Micro Devices Inc. |
|---|---|
| Model Number | NJU77551F-TE1 |
| Minimum Order Quantity | 1 |
| Price | Based on current price |
| Packaging Details | anti-static bag & cardboard box |
| Delivery Time | 3-5 work days |
| Payment Terms | T/T |
| Supply Ability | In stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Amplifier Type | General Purpose | Number Of Circuits | 1 |
|---|---|---|---|
| Output Type | Rail-to-Rail | Slew Rate | 0.8V/µs |
| Gain Bandwidth Product | 1.7 MHz | -3db Bandwidth | - |
| Current - Input Bias | 1 PA | Voltage - Input Offset | 1 MV |
| Current - Supply | 55µA | Current - Output / Channel | 60 MA |
| Voltage - Supply Span (Min) | 1.8 V | Voltage - Supply Span (Max) | 5.5 V |
| Operating Temperature | -55°C ~ 125°C | Mounting Type | Surface Mount |
| Package / Case | SC-74A, SOT-753 | Supplier Device Package | SOT-23-5 (MTP5) |
You can tick the products you need and communicate with us in the message board.
| Part Number | Description | |
|---|---|---|
| NJU77551F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJM2730F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU77550F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7026F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7056F-TE1 | IC CMOS 1 CIRCUIT SOT23-5 | |
| NJM2125F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJM2741F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJM8530F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7046F-TE2 | IC CMOS 1 CIRCUIT SOT23-5 | |
| NJU7011F-TE1# | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU77701F-TE2 | IC CMOS 1 CIRCUIT SOT23-5 | |
| NJU77001F-TE2 | IC CMOS 1 CIRCUIT SOT23-5 | |
| NJM2716F-TE1# | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7076F-TE1 | IC CMOS 1 CIRCUIT SOT23-5 | |
| NJU7091AF-TE1# | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7092AF-TE1# | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7040F-TE1 | IC CMOS 1 CIRCUIT SOT23-5 | |
| NJU7093AF-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7006F-TE1# | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU77000F-TE2 | IC CMOS 1 CIRCUIT SOT23-5 | |
| NJM2711F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7091AF-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7092AF-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJM2716F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7006F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 | |
| NJU7011F-TE1 | IC OPAMP GP 1 CIRCUIT SOT23-5 |
Product Description
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Product Category | Instrumentation Amplifier |
| Mfr | Nisshinbo Micro Devices Inc． |
| Series | - |
| Package | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® |
| Product-Status | Active |
| Amplifier-Type | General Purpose |
| Number-of-Circuits | 1 |
| Output-Type | Rail-to-Rail |
| Slew-Rate | 0．8V/µs |
| Gain-Bandwidth-Product | 1．7 MHz |
| Current-Input-Bias | 1 pA |
| Voltage-Input-Offset | 1 mV |
| Current-Supply | 55µA |
| Current-Output-Channel | 60 mA |
| Voltage-Supply-Span-Min | 1．8 V |
| Voltage-Supply-Span-Max | 5．5 V |
| Operating-Temperature | -55°C ~ 125°C |
| Mounting-Type | Surface Mount |
| Package-Case | SC-74A SOT-753 |
| Supplier-Device-Package | SOT-23-5 (MTP5) |
| Base-Product-Number | NJU77551 |
