BA10324AF-E2 IC OPAMP GP 4 CIRCUIT 14SOP Rohm Semiconductor
| Brand Name | Rohm Semiconductor |
|---|---|
| Model Number | BA10324AF-E2 |
| Minimum Order Quantity | 1 |
| Price | Based on current price |
| Packaging Details | anti-static bag & cardboard box |
| Delivery Time | 3-5 work days |
| Payment Terms | T/T |
| Supply Ability | In stock |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Amplifier Type | General Purpose | Number Of Circuits | 4 |
|---|---|---|---|
| Output Type | - | Slew Rate | 0.2V/µs |
| Gain Bandwidth Product | 500 KHz | -3db Bandwidth | - |
| Current - Input Bias | 20 NA | Voltage - Input Offset | 2 MV |
| Current - Supply | 600µA | Current - Output / Channel | 35 MA |
| Voltage - Supply Span (Min) | 3 V | Voltage - Supply Span (Max) | 32 V |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (0.173", 4.40mm Width) | Supplier Device Package | 14-SOP |
You can tick the products you need and communicate with us in the message board.
| Part Number | Description | |
|---|---|---|
| BA10324AF-E2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BA2902SF-E2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BA3474F-E2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BU7264F-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| LMR934F-GE2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| LM324F-GE2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BU7244F-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BA14741F-E2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BA2902YF-LBH2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BA4584RF-E2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BU7487F-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7444SF-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7464SF-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BA2902F-E2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BA82902YFJ-CE2 | IC OPAMP GP 4 CIRCUIT 14SOPJ | |
| LMR324F-GE2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| BU7464F-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7294F-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7444F-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7487SF-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7294SF-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| LMR824F-GE2 | IC OPAMP GP 4 CIRCUIT 14SOP | |
| LMR344F-GE2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7244SF-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| BU7264SF-E2 | IC CMOS 4 CIRCUIT 14SOP | |
| LM324F-E2 | IC OPAMP GP 4 CIRCUIT 14SOP |
Product Description
Product Details
ROHM’s Selection Operational Amplifier / Comparator Series Operational Amplifiers: Ground Sense
Description
General-purpose BA10358/BA10324A family and high-reliability BA2904S/BA2904/BA2902S/BA2902 family and automotive BA2904HFVM-C integrate two or four independent Op-Amps andphase compensation capacitors on a single chip andhave some features of high-gain, low power consumption,and operating voltage range of 3[V] to 32[V] (single powersupply ).BA3404 family is realized high speed operation andreduce the crossover distortions that compare with BA10358/ BA2904 family.
Characteristics
1) Operable with a single power supply2) Wide operating supply voltage
+3.0[V]～ +32.0[V](single supply)
(BA10358/BA10324A/BA2904S/BA2904/BA2902S/BA2902 family,BA2904HFVM-C)
+4.0[V]～ +36.0[V](single supply)
(BA3404 family)
3) Standard Op-Amp Pin-assignments
4) Input and output are operable GND sense
5) Internal phase compensation type
6) Low supply current
7) High open loop voltage gain
8) Internal ESD protection
Human body model(HBM) ±5000[V](Typ.)
(BA2904S/BA2904/BA2902S/BA2902/BA3404 family,BA2904HFVM-C)
9) Gold PAD (BA2904S/BA2904/BA2902S/BA2902/BA3404 family,BA2904HFVM-C)
10) Wide temperature range
-40[℃ ]～ +125[℃ ] (BA2904/BA2902 family,BA2904HFVM-C)
-40[℃ ]～ +105[℃ ] (BA2904S/BA2902S family)
-40[℃ ]～ +85[℃ ] (BA10358/BA10324/BA3404 family)
Specifications
| Attribute | Attribute Value |
|---|---|
| Manufacturer | ROHM |
| Product Category | Instrumentation Amplifier |
| Series | BA10324A |
| Product | Operational Amplifiers |
| Packaging | Reel |
| Unit-Weight | 0.008501 oz |
| Mounting-Style | SMD/SMT |
| Technology | Bipolar |
| Number-of-Channels | 4 Channel |
| Amplifier-Type | Ground Sense Amplifier |
| Shutdown | No Shutdown |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | - 40 C |
| Operating-Supply-Current | 600 uA |
| Supply-Voltage-Max | 32 V |
| Supply-Voltage-Min | 3 V |
| Package-Case | SOP-14 |
| Ib-Input-Bias-Current | 250 nA |
| Vos-Input-Offset-Voltage | 7 mV |
| PSRR-Power-Supply-Rejection-Ratio | 65 dB |
| Output-Current-per-Channel | 35 mA |
| CMRR-Common-Mode-Rejection-Ratio | 65 dB |
| GBP-Gain-Bandwidth-Product | 500 kHz |
| SR-Slew-Rate | 0.2 V/us |
| Maximum-Dual-Supply-Voltage | +/- 16 V |
| Minimum-Dual-Supply-Voltage | +/- 1.5 V |
Functional compatible component
Form,Package,Functional compatible component
| Manufacturer Part# | Description | Manufacturer | Compare |
| BA10324AFE2 Amplifier Circuits |
QUAD OP-AMP, 7000uV OFFSET-MAX, 0.5MHz BAND WIDTH, PDSO14, ROHS COMPLIANT, SOP-14 | ROHM Semiconductor | BA10324AF-E2 vs BA10324AFE2 |
| BA10324AF-E1 Amplifier Circuits |
Operational Amplifier, 4 Func, 7000uV Offset-Max, BIPolar, PDSO14, SOP-14 | ROHM Semiconductor | BA10324AF-E2 vs BA10324AF-E1 |
| BA10324AF Amplifier Circuits |
Operational Amplifier, 4 Func, 7000uV Offset-Max, BIPolar, PDSO14, ROHS COMPLIANT, SOP-14 | ROHM Semiconductor | BA10324AF-E2 vs BA10324AF |
Descriptions
General Purpose Amplifier 4 Circuit 14-SOP
Operational Amplifiers - Op Amps OPAMP QUAD 32V
